48 ... 253 V AC / 20 ... 90 V DC
KFU8-UFC-1
GND
RXD
TXD
1-channel
Input frequency 1 mHz ... 12 kHz
Analogue output 0/4 mA ... 20 mA
Measuring range parameterizable
2 relay outputs
1 electronic output, isolated
Each output can be assigned indivi-
dual parameters, such as a limiting
value (high/low alarm), incremen-
ting, pulse separator or error mes-
sage output
Start-up override
Restart inhibit
Lead breakage (LB) and short-circuit
(SC) monitoring
Bounce filter
Parameterization via PC or control
panel (optional)
1+
3-
1+ 10 k
3-
1+
3(+)
2-
1
2
3
K-ADP1
RS 232
PC
Signal processor
TTL
yellow/
red
green
U
yellow
yellow
yellow
Output
III
Output
II
Output
I
48 ... 253 V AC / 20 ... 90 V DC
KFU8-UFC-1.D
Output
IV
0/4 ... 20mA
KFU8-UFC-1
KFU8-UFC-1.D
(with control panel)
13+ 14-
10 11 12
16 17 18 19+ 20-
8+ 7-
Collective
error
indication*
23-
24+
Start bridge
*KFD2-UFC-... only
Power rail
Aufbau
