IDC Systems
Female Sockets
P
RODUCT
D
ESCRIPTION
The Thomas & Betts Female Socket
Connectors are designed to mate
with a wide variety of Male Headers in
PC board applications which require
repeated connection and
disconnection. The connectors
provide fast, high-integrity mass
termination of all types of flat cable,
simplifying and improving the quality
of electronic interconnection. All
Female Socket Connectors are UL
recognized and CSA certified.
FEMALE SOCKET
CONNECTORS
D
ESIGN
A
DVANTAGES
鈥?Choice of contact materials and
gold plating thicknesses.
鈥?Available in .050 x .100, .100 x
.100, .100 x .200 and .100 x .300
configurations.
鈥?Optional polarizing plug provides
positive keying.
鈥?Optional polarizing tab insures
positive mating direction.
SOCKET INDEX
.050" x .100" Fine Pitch ............................................................8
.100" x .100" w/ 30碌 Gold ........................................................9
.100" x .100" w/ 15碌 Gold ......................................................10
.100" x .100" I/O Ultra ATA w/ 15碌 Gold for .025" Cable........11
.100" x .100" w/ Daisy Chain Strain Relief ..............................12
.100" x .200" & .100" x .300" Dip Socket ..............................14
Accessories..............................................................................15
