0R8GU41
TOSHIBA RECTIFIER SILICON DIFFUSED TYPE
0R8GU41
HIGH SPEED RECTIFIER APPLICATIONS
(FAST RECOVERY)
l
Average Forward Current
l
Repetitive Peak Reverse Voltage
l
Reverse Recovery Time
l
Plastic Mold Type
: I
F (AV)
= 0.8A (Ta = 40擄C)
: V
RRM
= 400V
: t
rr
= 100ns (Max)
Unit: mm
MAXIMUM RATINGS
(Ta = 25擄C)
CHARACTERISTIC
Repetitive Peak Reverse Voltage
Average Forward Current
(Ta = 40擄C)
Peak One Cycle Surge Forward
Current (Non鈭扲epetitive)
Junction Temperature
Storage Temperature Range
SYMBOL
V
RRM
I
F (AV)
I
FSM
T
j
T
stg
RATING
400
0.8
30 (50Hz)
33 (60Hz)
鈭?0~150
鈭?0~150
UNIT
V
A
A
擄C
擄C
JEDEC
JEITA
TOSHIBA
Weight: 0.3g
DO鈭?1
鈥?/div>
3鈭?C1A
ELECTRICAL CHARACTERISTICS
(Ta = 25擄C)
CHARACTERISTIC
Peak Forward Voltage
Repetitive Peak Reverse Current
Reverse Recovery Time
Forward Recovery Time
Thermal Resistance
Thermal Resistance
SYMBOL
V
FM
I
RRM
t
rr
t
fr
R
th (j鈭抋)
R
th (j鈭掆創(chuàng))
TEST CONDITION
I
FM
= 1.0A
V
RRM
= 400V
I
F
= 1.0A, di / dt =
鈭?0A
/ 碌s
I
F
= 1.0A
Junction to Ambient
Junction to Lead
MIN
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
MAX
1.5
50
100
200
115
45
UNIT
V
碌A
ns
ns
擄C / W
擄C / W
MARKING
1
2002-09-17
1
2
3
