鈥?/div>
Single port shielded RJ-45 connector with integrated
10/100 magnetics
Compatible with a variety of 10/100 transceiver ICs
Operating temperature 0擄 to +70擄 C
Storage temperature -40擄 to +85擄 C
鈥?/div>
BM01805
Complies with IEEE standards and all 10/100 Ethernet
specifications including 350碌H with 8mA DC bias
Integrated design conserves valuable board space
Minimum interwinding breakdown voltage of 1500 Vrms
Adaptable, modular design provides higher reliability
Staggered row pin configuration
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
ELECTRICAL SPECIFICATIONS AT 25擄 C
Common to
Differential
Mode
Rejection
dB min
60MHz to
80MHz
-12
Common to
Common
Mode
Rejection
dB min
Part Number
Insertion
Loss
dB max
Return Loss
dB min
Crosstalk
dB min
1MHz to
100MHz
0817-1A1T-11
-1.0
1MHz to
30MHz
-18
30MHz to
60MHz
18 - 20 log
(f/30MHz)
18 - 20 log
(f/30MHz)
100kHz to 100MHz
500kHz to 100MHz
-40
-30
-30
0817-1G1T-21
-1.0
-18
-12
-40
-30
-30
SCHEMATIC
0817-1A1T-11
LED2
Green
10
1CT : 1
1 TX+
0817-1G1T-21
(AutoMDIX)
RJ45
LED2
9
Green
10
TD+ 1
TD-
2
9
RJ45
TD+ 1
TCT 2
TD-
3
1CT : 1
1 TX+
2 TX-
TCT 3
RCT 6
RD+ 7
RD- 8
GND 4
GND 5
11
Yellow
12
LED1
Shield
1000pF
2kV
75鈩?/div>
x4
2 TX-
1CT : 1
3 RX+
4
5
6 RX-
7
8
RD+ 4
RCT 5
RD- 6
GND 8
11
Green
12
LED1
1CT : 1
3 RX+
4
5
6 RX-
7
8
75鈩?/div>
x4
1000pF
2kV
Shield
漏2001 Bel Fuse Inc.
Specifications subject to change without notice. 08.01
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
