0816-1X1T-23 Datasheet

  • 0816-1X1T-23

  • 1port.No LEDs.RJ45 10/100/1000 Gigabit Ethernet

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

INTEGRATED CONNECTOR MODULES
Gigabit belMag鈩?/div>
BM01809
鈥?/div>
Single port shielded RJ-45 connector with integrated
Gigabit Ethernet magnetics
Compatible with a variety of Gigabit Ethernet
transceiver ICs and 10/100Base-TX transceiver ICs
Operating temperature 0擄 to +70擄 C
鈥?/div>
Complies with IEEE 802.3ab standards and all Gigabit
Ethernet specifications
Integrated design conserves valuable board space
Minimum interwinding breakdown voltage of 1500 Vrms
Adaptable, modular design provides higher reliability
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Storage temperature -40擄 to +85擄 C
ELECTRICAL SPECIFICATIONS AT 25擄 C
Common to
Differential Mode
Rejection
dB min
100KHz to
100MHz
-40
Common to
Common Mode
Rejection
dB min
100KHz to
100MHz
-30
33 - 20 log
(f/50MHz)
33 - 20 log
(f/50MHz)
1500
Insertion Loss
dB max
Part Number
0.1MHz
to 100MHz
0813-1X1T-23
-1.0
Return Loss
dB min
Crosstalk
dB min
Hipot
Vrms
min
0.5MHz
to 40MHz
-18
40MHz
to 100MHz
12 - 20 log
(f/80 MHz)
12 - 20 log
(f/80 MHz)
0816-1X1T-23
-1.0
-18
-40
-30
1500
Available Options
鈥?Various transformer turns ratios
鈥?Various high voltage capacitor values
漏2001 Bel Fuse Inc.
Specifications subject to change without notice. 08.01
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
