INTEGRATED CONNECTOR MODULES

10/100Base-TX Extended Temp belMag鈩?with LEDs

鈥?/div>

Extended operating temperature -40擄 to +85擄 C

Storage temperature -40擄 to +85擄 C

鈥?/div>

Design supports AutoMDIX applications

鈥?/div>

Single port shielded RJ-45 connector with integrated

10/100 magnetics

Compatible with a variety of 10/100 transceiver ICs

鈥?/div>

Minimum interwinding breakdown voltage of 1500 Vrms

Adaptable, modular design provides higher reliability

Reduced pin count for improved crosstalk and optimum

PCB trace routing

Integrated design conserves valuable board space

鈥?/div>

BM01808

Complies with IEEE standards and all 10/100 Ethernet

specifications including 350碌H with 8mA DC bias

鈥?/div>

ELECTRICAL SPECIFICATIONS AT 25擄 C

Common to

Differential

Mode

Rejection

dB min

60MHz to

80MHz

-12

Common to

Common

Mode

Rejection

dB min

1MHz

Part Number

Insertion

Loss

dB max

Return Loss

dB min

Crosstalk

dB min

1MHz to

100MHz

0810-1X1T-36

-1.0

1MHz to

30MHz

-18

30MHz to

60MHz

18 - 20 log

(f/30MHz)

100kHz to 100MHz

30MHz

50MHz

100MHz

-40

-30

-70

-45

-40

-35

SCHEMATIC

0810-1X1T-36

Chip Side

LED1

Yellow

Green/Orange

LED2

Shield

1CT : 1

Line Side

RJ45

Available Options

75鈩?/div>

1000pF

2kV

鈥?Various transformer turns ratios

鈥?Various high voltage capacitor values

鈥?Various LED color combinations

漏2001 Bel Fuse Inc.

Specifications subject to change without notice. 11.01

Bel Fuse Inc.

206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com

page 1
