鈥?/div>
Reduced pin count for improved crosstalk and optimum
PCB trace routing
Adaptable, modular design provides higher reliability
Minimum interwinding breakdown voltage of 1500 Vrms
Integrated design conserves valuable board space
鈥?/div>
BM01826
Complies with IEEE 802.3 standards and all 10Base-T
Ethernet standards
ELECTRICAL SPECIFICATIONS AT 25擄 C
Insertion Loss
dB max
Part Number
1MHz to 10MHz
1MHz to 10MHz
Return Loss
dB min
Common to Common
Mode Rejection
dB min
Crosstalk
dB min
OCL
碌H min
10MHz to 30MHz
100kHz to 100MHz
TX
RX
0810-1X1T-27
-1.0
-18
-40
-40
45
230
SCHEMATICS
0810-1X1T-27
LED1
7
Yellow
8
TCT
1
1CT : 2.5
RJ45
1
TX+
TD+ 2
TD-
3
1CT : 1
2
TX-
Available Options
鈥?Various transformer turns ratios
鈥?Various LED color combinations
RD+ 4
RD-
5
RCT 6
9
Green
10
LED2
Orange
3 RX+
4
5
6 RX-
7
8
Shield
漏2001 Bel Fuse Inc.
Specifications subject to change without notice. 08.01
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
