Advance Product Datasheet
June 10, 2003
9.9-11.2Gb/s Optical Modulator Driver
OC-192 Metro and Long Haul Applications
Surface Mount Package
TGA4953-EPU
Key Features and Performance
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Metro MSA Compatible
Wide Drive Range (3V to 10V)
Single-ended Input / Output
Low Power Dissipation (1W at Vo=6V)
Very Low Rail Ripple
25 ps Edge Rates (20/80)
Small Form Factor
- 11.4 x 8.9 x 2 mm
- 0.450 x 0.350 x 0.080 inches
Evaluation Board Available.
鈥?/div>
Description
The TriQuint TGA4953-EPU is part of a series of surface
mount modulator drivers suitable for a variety of driver
applications and is compatible with Metro MSA standards.
The 4953 consists of two high performance wideband
amplifiers combined with off chip circuitry assembled in a
surface mount package. A single 4953 placed between
the MUX and Optical Modulator provides OEMs with a
board level modulator driver surface mount solution.
The 4953 provides Metro and Long Haul designers with
system critical features such as: low power dissipation
(1.1 W at Vo=6 V), very low rail ripple, high voltage drive
capability at 5V bias (6 V amplitude adjustable to 3 V), low
output jitter (10 ps typical), and low input drive sensitivity
(250 mV at Vo=6 V).
The 4953 requires external DC blocks, a low frequency
choke, and control circuitry.
The TGA4953-EPU is available on an evaluation board.
Primary Applications
鈥?/div>
Mach-Zehnder Modulator Driver for
Metro and Long Haul.
Measured Performance
TGA4953 Evaluation Board (Metro MSA Conditions)
10.7 Gb/s, Vplus=5 V, Id=210 mA, (Pdc=1.1 Watt)
Vout=6 Vpp, CPC=50%, Vin = 500 mVpp
Scale: 2 V/div, 15 ps/div
Note: Devices designated as EPU are typically early in their characterization process prior to finalizing all electrical and process
specifications. Specifications are subject to change without notice.
1
TriQuint Semiconductor Texas : (972)994 8465
Fax (972)994 8504 Web: www.triquint.com
