Able Systems Limited

Northwich, Cheshire, England

www.able-systems.com

USERS' GUIDE

to the

ABLE SYSTEMS A104B

Printer Controller Board

Contents

1

2

3

4

5

Appendices

Introduction

On-line Information

Pin Connections

Installation

Operation and Programming

EMC Disclaimer, PCB Layout & Schematic

1 Introduction

This document is a Users' Guide, written for the person designing-in, connecting and using the Able

Systems A104B printer controller board for the EPSON M-160 series of 4-needle mini-printer

mechanisms. Please read it carefully before making any connection. The A104B is an enhanced

replacement for the A160B series of controller boards, and shares many features of the range. Every

effort has been made to simplify the transition for existing customers, but of necessity some of the

connections are slightly different.

Throughout this document, the designation A160B can generally be taken to represent the A150B,

A160B, A163B, A164B, and national variants of these products.

2 On-Line Information

Able Systems maintains a site on the World Wide Web. This includes application data updates,

product announcements, and e-mail facilities for customer support.

The

URL

of our

web site

is:

Our

e-mail address

is:

http://www.able-systems.com

contact@able-systems.com

COPYRIGHT NOTICE and DISCLAIMER

Note that copyright subsists in all Able Systems intellectual property, including controller firmware (embedded software) and

circuit diagrams, pin connection lists and application data. No warranty in respect of patent rights of Able Systems Limited or

of third parties is given. Unauthorised reproduction or amendment of controller firmware may result in prosecution.

Note: EPSON is a registered mark of its owner Seiko Epson Corporation. References to this or other owners' marks in this

document are for illustrative purposes only.
