T-1
3
/
4
(5 mm), T-1 (3 mm), Low
Current, Double Heterojunction
AlGaAs Red LED Lamps
Technical Data
HLMP-D150/D155
HLMP-K150/K155
Features
鈥?Minimum Luminous Inten-
sity Specified at 1 mA
鈥?High Light Output at Low
Currents
鈥?Wide Viewing Angle
鈥?Outstanding Material
Efficiency
鈥?Low Power/Low Forward
Voltage
鈥?CMOS/MOS Compatible
鈥?TTL Compatible
鈥?Deep Red Color
Applications
鈥?Low Power Circuits
鈥?Battery Powered Equipment
鈥?Telecommunication
Indicators
Description
These solid state LED lamps
utilize newly developed double
heterojunction (DH) AlGaAs/GaAs
material technology. This LED
material has outstanding light
output efficiency at very low drive
currents. The color is deep red at
the dominant wavelength of 637
nanometres. These lamps are
ideally suited for use in
applications where high light
output is required with minimum
power output.
Package Dimensions
24.10 (0.95)
MIN.
A
B
C
1
2
3
4
