High temperature soldering guaranteed:
260擄C/10 seconds at 5 lbs. (2.3kg) tension
0.130 (3.3)
0.120 (3.05)
0.045 (1.14)
0.035 (0.89)
0.023 (0.58)
0.018 (0.46)
0.205 (5.2)
0.195 (5.0)
0.080 (2.03)
0.050 (1.27)
0.185 (4.69)
0.150 (3.81)
0.075 (1.90)
0.055 (1.39)
0.013 (3.3)
0.0086 (0.22)
MECHANICAL DATA
Case:
Molded plastic body over passivated junctions
Terminals:
Plated lead solderable per MIL-STD-750,
Method 2026
Polarity:
Polarity symbols marked on body
Mounting Position:
Any
Weight:
0.04 ounce, 1.0 gram
0.350 (8.9)
0.300 (7.6)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25擄C ambient temperature unless otherwise specified.
SYMBOLS
DF
005M
DF
01M
DF
02M
DF
04M
DF
06M
DF
08M
DF
10M
UNITS
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward output rectified current
at T
A
=40擄C
Peak forward surge current single sine-wave
superimposed on rated load (JEDEC Method)
Rating for fusing (t < 8.3ms)
Maximum instantaneous forward voltage drop
per leg at 1.0A
Maximum reverse current
at rated DC blocking voltage per leg
Typical junction capacitance per leg
(NOTE 1)
Typical thermal resistance per leg
(NOTE 2)
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
T
A
=25擄C
T
A
=125擄C
I
R
C
J
R
螛JA
R
螛JL
T
J
, T
STG
50
35
50
100
70
100
200
140
200
400
280
400
1.0
50.0
10.0
1.1
5.0
500.0
25.0
40.0
15.0
-55 to +150
600
420
600
800 1000 Volts
560
700
Volts
800 1000 Volts
Amp
Amps
A
2
sec
Volts
碌A(chǔ)
pF
擄C/W
擄C
Operating junction and storage temperature range
NOTES:
(1) Measured at 1.0 MH
Z
and applied reverse voltage of 4.0 Volts
(2) Thermal resistance from junction to ambient and from junction to lead mounted on
P.C.B. with 0.5 x 0.5" (13 x 13mm) copper pads
