RECTRON
SEMICONDUCTOR
TECHNICAL SPECIFICATION
05A1
THRU
05A7
SURFACE MOUNT SILICON RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts CURRENT 0.5 Ampere
FEATURES
*
*
*
*
*
Ideal for surface mounted applications
Low leakage current
Metallurgically bonded construction
Mounting position: Any
Weight: 0.016 gram
.150 (3.80)
.142 (3.60)
MECHANICAL DATA
* Epoxy : Device has UL flammability classification 94V-0
.031 (0.80)
.028 (0.70)
.067 (1.70)
.059 (1.50)
.106 (2.70)
.098 (2.50)
.051 (1.30)
.050 (1.26)
.016 (0.40)
.008 (0.20)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
MAXIMUM RATINGS
(At T
A
= 25
o
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
o
Maximum Average Forward Rectified Current at T
A
= 55 C
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
(Note 2) R胃
JL
(Note 3) R胃
JA
C
J
T
J
, T
STG
05A1
50
35
50
05A2
100
70
100
05A3
200
140
200
05A4
400
280
400
0.5
15
70
120
8
-65 to + 150
05A5
600
420
600
05A6
800
560
800
05A7
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
0
0
Peak Forward Surge Current I
FM
(surge): 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Thermal Resistance
Typical Junction Capacitance (Note 1)
Operating and Storage Temperature Range
ELECTRICAL CHARACTERISTICS
(At T
A
= 25
o
C unless otherwise noted)
CHARACTERISTICS
Maximum Forward Voltage at 0.5A DC
Maximum Full Load Reverse Current,
Full cycle Average at T
A
= 55
o
C
Maximum DC Average Reverse Current at
Rated DC Blocking Voltage
@T
A
= 25 C
@T
A
= 100 C
o
o
C/ W
C/ W
pF
0
C
SYMBOL
V
F
05A1
05A2
05A3
05A4
1.1
30
05A5
05A6
05A7
UNITS
Volts
uAmps
uAmps
uAmps
2001-11
I
R
5.0
50
NOTES : 1. Measured at 1.0 MHz and applied average voltage of 4.0VDC
2. Thermal resistance junction to terminal 6.0mm
2
coppeer pads to each terminal.
3. Thermal resistance junction to ambient, 6.0mm
2
coppeer pads to each terminal.
