Using a PCI Bus as the I/O Bus on an

Am29030t Microprocessor Design

Application Note

by David Stoenner

Advanced

Micro

Devices

This application note describes how the Peripheral Component Interconnect (PCI) bus can be used

as the I/O bus portion on a two-bus microcontroller design. Additionally, one programmable logic part,

the MACH

r

220 device, is added for the entire control logic for both the memory control and the signal

conversion between the Am29030

t

microprocessor and Revision 2.0 of the PCI I/O bus.

INTRODUCTION

The Peripheral Component Interconnect (PCI) local bus

is a high-performance, 32-bit or 64-bit bus with multi-

plexed address and data lines. It is intended for use as

an interconnect mechanism between highly integrated

peripheral controller components, peripheral add-in

boards, and processor/memory systems. Because the

bus is multiplexed, the number of pin contacts is re-

duced, making the peripheral cheaper to implement. To

accomplish this, PCI adds a layer between the CPU and

the peripherals, resulting in a processor-independent

bus that can be used for a variety of CPUs and proces-

sor speeds.

The PCI bus is a well-defined interface that is specified

for the signals as well as the physical characteristics of

the connector and the loading. Since inexpensive pe-

ripherals will become available to meet PC needs, it

would therefore be advantageous to extend the use of

the PCI bus into the embedded processor market. Since

the 29Kt Family is one of the premiere RISC families

used in embedded control, this application note shows

how easily the PCI bus can be adapted to the 29K Fami-

ly processor to meet the requirement of an I/O bus.

Arbitration on the PCI bus ranges from a simple design

of direct priority to a more complicated design of using

arbitration under the existing bus master for the next bus

master. The protocol also supports bus master preemp-

tion if desired. Additionally, complex caching cycles for

multiprocessors also are defined. With forethought, the

PCI SIG specified that these features be optional and

not required.

Use of the PCI Bus in this Design

This design focuses on the minimum requirements of

the PCI bus, with the exception of parity. Currently, parity

is not supported on this design because of the complex-

ity of the chips that would need to be added to the de-

sign. Bus master arbitration is limited to the Am29030

processor 鈥減arked鈥?on the PCI bus being the main mas-

ter, and the peripheral chips requesting the bus as nec-

essary. No support for time-out and bus master

preemption is included, so it is the responsibility of each

master to ensure that each peripheral does not use the

bus to the exclusion of the other peripherals.

The memory design is taken directly from the original

EZ-030 demonstration board (see the

EZ-030 Demon-

stration Board Theory of Operation

application note),

except that the MACH220 device replaces all the dis-

crete PALr devices of the EZ-030 board design. Since

the EZ-030 board supports a memory clock (MEMCLK)

of 16 MHz, this application note also focuses at 16 MHz

for both the memory and the PCI bus clock. The PCI bus

clock is defined from 0 to 33 MHz, so this falls within that

limit. Also, 33-MHz clock rates, and therefore the bus,

require more careful layout than the 16-MHz clock.

The rest of this application note focuses on the

MACH220 device and the extra circuitry needed to im-

plement the control portion of the PCI bus. Schematics

for this design are shown in Appendix A and the PAL

equations are listed in Appendix B.

THE PCI BUS

In order to create an industry standard for PCI, the PCI

Special Interest Group (SIG) has defined a specifica-

tion. The

PCI Local Bus Specification,

Revision 2.0, de-

fines the protocol, electrical, mechanical, and

configuration specifications for PCI local bus compo-

nents and expansion boards. (See page 5 for informa-

tion on ordering the specification.)

Basics of the PCI Bus

The PCI bus is an address/data multiplexed bus. Addi-

tionally, the control signals are multiplexed with the byte

control signals. The PCI bus supports a burst protocol

that accepts an address with multiple data packets. This

protocol is identical to the 29K Family, making the inter-

face design easily accomplished.

Publication#

18468

Rev.

A

Issue Date:

May 1994

Amendment

/0
