Blade Terminal & Special Purpose Fuses
Low Voltage
RoHS
MEGA
廬
Slo-Blo
廬
Fuse
Designed for high current circuit protection up to 250
amperes. Ideal for battery and UPS systems requiring
ultra-high current protection.
ELECTRICAL CHARACTERISTICS:
% of Ampere
Rating
100%
135%
200%
350%
600%
Opening
Time
4 Hours,
Minimum
120 sec.,
Min.;
1800 sec.,
Max.
1 sec.,
Min.;
15 sec.,
Max.
0.3 sec.,
Min.;
5 sec.,
Max.
0.1 sec.,
Min.;
1 sec.,
Max.
PHYSICAL SPECIFICATIONS:
Materials:
Body: Plastic
Terminations: Copper
PATENTED
INTERRUPTING RATING:
2000A @ 32 VDC
50.8 (2.0")
19.05 (.75")
(1.15")
68.58 (2.70")
10.67 (.42")
8.64 (.34")
16.26 (.64")
11.94 (.47")
1.02 (.04")
ORDERING INFORMATION:
Catalog
Number
298
040
298
060
298
080
298
100
298
125
298
150
298
175
298
200
298
225
298
250
Ampere
Rating
(A)
40
60
80
100
125
150
175
200
225
250
Voltage
Rating
(VDC)
32
32
32
32
32
32
32
32
32
32
Stamp
Color
Code
TBD
TBD
TBD
Yellow
Green
Orange
White
Blue
Tan
Pink
Nominal Cold
Resistance
(milliOhms)
TBD
TBD
TBD
0.55
0.43
0.35
0.27
0.26
0.23
0.19
Minimum
Melting I
2
t
(A
2
Sec.)
TBD
TBD
TBD
31100
57800
100000
168000
204000
257000
389000
Average Time Current Curves
40A
60A
80A
100A
125A
150A
175A
200A
225A
250A
1000
100
MEGA
廬
Fuse Holder
ORDERING INFORMATION:
Catalog
Number
0298
1001
0298
2001
Version
Single Holder Assembly
Dual Holder Assembly
12
BLADE TERMINAL AND
SPECIAL PURPOSE FUSES
10
100
1000
10000
CURRENT IN AMPERES
TIME IN SECONDS
10
1
0.1
0.01
