鈥?Designed to International (IEC) Standards for use globally.
鈥?Meets the IEC 60127-2, Sheet 6 specification for Time Lag Fuses.
鈥?Available in Cartridge and Axial Lead Format.
鈥?Available in ratings of 1.0 to 6.3 amperes.
鈥?/div>
RoHS compliant and Lead-Free version available, add XP suffix to
standard catalog number
ELECTRICAL CHARACTERISTICS:
% of Ampere
Rating
150%
210%
275%
400%
1000%
power factor
Opening
Time
60 minutes,
Minimum
2 minutes,
Maximum
0.6 sec.,
Min.;
10 sec.
Max
.15 sec.,
Min.;
3 sec.
Max
0.02 sec.,
Min.;
0.3 sec.
Max.
INTERRUPTING RATINGS:
150 amperes @ 250VAC, unity
ORDERING INFORMATION:
RoHS compliant and Lead-Free version available, add XP suffix to
standard catalog number
Catalog
Number
0219.125A
0219.160A
0219.200A
0219.250A
0219.315A
0219.400A
0219.500A
0219.630A
0219.800A
0219
001.A
0219
1.25A
0219
01.6A
0219
002.A
0219
02.5A
0219
3.15A
0219
004.A
0219
005.A
0219
06.3A
Ampere
Rating
.125
.160
.200
.250
.315
.400
.500
.630
.800
1
1.25
1.6
2
2.5
3.15
4
5
6.3
Nominal
Voltage
Rating
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
Nominal
Resistance
Cold Ohms
4.41
2.44
1.60
1.05
0.848
0.535
0.370
0.275
0.163
0.117
0.082
0.055
0.046
0.031
0.023
0.016
0.012
0.011
Nominal
Melting I
2
t
A
2
Sec
0.150
0.225
0.350
0.555
1.14
1.35
2.90
4.80
1.99
19.2
27.2
44.2
92.7
138.0
202.1
330.0
544.0
1093.0
ENVIRONMENTAL SPECIFICATIONS:
Operating temperature:
-55藲C to 125藲C
Thermal Shock:
MIL-STD-202F Method 107G, Test Condition B: (5
cycles 鈥?5擄C to +125擄C)
Vibration:
MIL-STD-202F Method 201A
Humidity:
MIL-STD-202F Method 103B, Test Condition A. high relative
humidity (95%) and elevated temperature (40擄C) for 240 hours.
Salt Spray:
MIL-STD-202F Method 101D, Test Condition B
PHYSICAL SPECIFICATIONS:
Material:
Body: Glass
Cap: Nickel Plated Brass
Leads: Tin Plated Copper
Terminal Strength:
MIL-STD-202F Method 211A,
Test Condition A
Solderability:
Reference IEC 60127 Second Edition 2003-01 Annex A
Product Marking:
Cap 1: current and voltage rating.
Cap 2: Agency approval markings.
Packaging:
Available in Bulk (v=5, H=100, M=1000 pcs/pkg) or on
Tape/Reel (MRET1=1000 pcs/reel).
420
