Miniature PCB Relay PE bistable
1pole 5 A, polarized bistable version
Features
路
路
路
路
路
路
1 C/O contact
Cadmium-free contacts
4 kV coil-contact
Insulation according to IEC 255
Ambient temperature 70 擄C
Low height 10.0 mm
Applications
Room thermostats, electricity meters, domotic devices and white
goods
F0221-A
VZ
1 C/O contact
single contact
5A
250 Vac / 440 Vac
1250 VA
AgNi 90/10
Technical data of approved types on request
Contact data
Configuration
Type of contact
Rated current
Rated voltage / max.breaking voltage AC
Maximum breaking capacity AC
Contact material
Contact ratings
Type
Load
PE 014
5A, 250 Vac, on the C/O contact
Operations
10
5
Standard
VDE 0435
Nominal voltage
3...48 Vdc
Nominal coil power
typ. 360 mW
Minimum energization time
20 ms
Information on reduced pulse duration with higher energization voltages on demand
Max. energization time
1 min at <10%duty cycle
Reset voltage max.
120 % U
nom
at -40 擄C
Coil data
Coil versions, bistable, 1 coil
Coil
Nominal
Pull-in
Reset
Coil
Coil
*
code
voltage
voltage
voltage
resistance
current
Vdc
Vdc
Vdc
c
mA
A03
C03
3
2.25
2.25
25+10%
120.0
A05
C05
5
3.75
3.75
69+10%
72.0
A06
C06
6
4.5
4.5
100+10%
60.0
A12
C12
12
9.0
9.0
400+10%
30.0
A24
C24
24
18.0
18.0
1600+10%
15.0
All figures are given for coil without preenergization, at ambient temperature +20擄C
*
Coil codes A.. and C.. have opposite polarity; refer to coil operation table
Other coil voltages on request
Coils - operation
version
coil terminals
pull-in
reset
Contact position not defined at delivery
Edition: 03/2002
A1
+
-
A..
A2
-
+
A1
-
+
C..
A2
+
-
1
2
