DF4-28DP-2C Datasheet

IC型號：
DF4-28DP-2C
PDF描述：
2mm Pitch Connector Directly Mounted on Board
文件大?。?/label>
237.71KB
PDF頁數：
7頁
芯片廠家：
HRS

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

sDouble

Row Crimping Plug

Photo: Contact insertion state

Applicable Through-hole Diameter 脴0.9鹵0.05

Note:The dip side may be deviated according to the cable thickness and the crimping contact bent up/down.

Unit:mm

Part Number

DF4-04DP-2C (**)

DF4-06DP-2C (**)

DF4-08DP-2C (**)

DF4-10DP-2C (**)

DF4-12DP-2C (**)

DF4-14DP-2C (**)

DF4-16DP-2C (**)

DF4-18DP-2C (**)

DF4-20DP-2C (**)

DF4-22DP-2C (**)

DF4-24DP-2C (**)

DF4-26DP-2C (**)

DF4-28DP-2C (**)

DF4-30DP-2C (**)

DF4-32DP-2C (**)

CL No.

544-0078-3-**

544-0079-6-**

544-0080-5-**

544-0081-8-**

544-0082-0-**

544-0083-3-**

544-0084-6-**

544-0085-9-**

544-0086-1-**

544-0087-4-**

544-0088-7-**

544-0089-0-**

544-0090-9-**

544-0091-1-**

544-0092-4-**

Number of Contacts

04.8

06.8

08.8

10.8

12.8

14.8

16.8

18.8

20.8

22.8

24.8

26.8

28.8

30.8

32.8

02.0

04.0

06.0

08.0

10.0

12.0

14.0

16.0

18.0

20.0

22.0

24.0

26.0

28.0

30.0

[Specific No.] 鈥?**, (**)

Blank: 1 bag: 100pcs.

Note 1.The quantity at the specific No. "None" is delivered per bag (100pcs.). If needed, please order the products per bag.

B173

prev next

DF4-28DP-2C 產品屬性

標準包裝
100
類別
連接器，互連式
家庭
矩形 - 外殼
系列
DF4
連接器類型
插頭
觸點類型：
公形引腳
位置數
28
間距
0.079"（2.00mm）
行數
2
行間距
0.079"（2.00mm）
安裝類型
通孔
觸點終端
壓接
緊固型
-
顏色
黑
特點
-
包裝
散裝
請注意
不提供觸點
相關產品
H11367-ND - CONN TERM 24-28AWG CRIMP TINH11367CT-ND - CONN TERM 24-28AWG CRIMP TINH11367TR-ND - CONN TERM 24-28AWG CRIMP TINH2612CT-ND - CONN TERM 24-28AWG CRIMP TINH2612-ND - CONN TERM 24-28AWG CRIMP TINH2612TR-ND - CONN TERM 24-28AWG CRIMP TIN
其它名稱
*DF4-28DP-2CH2608

DF4-28DP-2C相關型號PDF文件下載
