DF4-28DP-2C Datasheet

IC型號：
DF4-28DP-2C
PDF描述：
2mm Pitch Connector Directly Mounted on Board
文件大?。?/label>
237.71KB
PDF頁數：
7頁
芯片廠家：
HRS

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

sSingle

Row Crimping Plug

[Specific No.] 鈥?**, (**)

Blank: 1 bag: 100pcs.

(40): 500pcs. packaging

(41): 1000pcs. packaging

Photo: Contact insertion state.

Applicable Through-hole Diameter : 脴0.8

+0.1

Unit:mm

Part Number

DF4- 2P-2C (**)

DF4- 3P-2C (**)

DF4- 4P-2C (**)

DF4- 5P-2C (**)

DF4- 6P-2C (**)

DF4- 7P-2C (**)

DF4- 8P-2C (**)

CL No.

544-0003-4-**

544-0004-7-**

544-0005-0-**

544-0006-2-**

544-0007-5-**

544-0008-8-**

544-0009-0-**

Number of Contacts

04.5

06.5

08.5

10.5

12.5

14.5

16.5

02.0

04.0

06.0

08.0

10.0

12.0

14.0

Part Number

DF4- 9P-2C (**)

DF4-10P-2C (**)

DF4-11P-2C (**)

DF4-12P-2C (**)

DF4-13P-2C (**)

DF4-14P-2C (**)

DF4-15P-2C (**)

CL No.

544-0010-0- **

544-0011-2- **

544-0012-5- **

544-0013-8- **

544-0014-0- **

544-0015-3- **

544-0016-6- **

Number of Contacts

18.5

20.5

22.5

24.5

26.5

28.5

30.5

16.0

18.0

20.0

22.0

24.0

26.0

28.0

Note 1.The quantity at the specific No. "None" is delivered per bag (100pcs.). If needed, please order the products per bag.

sCrimping

Contact

Part Number

DF4-2428PCF

DF4-2428PC

CL No.

544-0020-3

544-0021-6

Packaging Type

Reel

Bag

Quantity

10,000

100

Finish

Tin plating

qApplicable

Cable (Tin plating Annealed copper wire)

Conductor Size

AWG24 (11 cores./0.16mm)

AWG 26 (7cores./0.16mm)

AWG 28 (7cores./0.127mm)

Recommended Cable

UL1061

UL1061/1007

Jacket Diameter

脴0.75 to 脴1.2mm

Note:If other cables are used instead of the applicable cable, contact Hirose sales

department.

Strip Length: 1.3 to 1.9mm

BApplicable

Crimping Tool

Type

Applicator

Press Main Unit

Part Number

AP105-DF4-2428P

CM-105

CL No.

901-4539-0

901-0005-4

550-0173-6

550-0179-2

Applicable Contact

DF4-2428PCF

鈥撯€撯€撯€撯€撯€撯€?/div>

DF4-2428PC

DF4-2428PCF

Manual Crimping Tool DF4-TA2428HC

Extraction Tool

DF-C-PO (B)

Note: If any trouble has occurred due to other tools, which are not designated by Hirose,

Hirose won't guarantee any products.

B172

prev next

DF4-28DP-2C 產品屬性

標準包裝
100
類別
連接器，互連式
家庭
矩形 - 外殼
系列
DF4
連接器類型
插頭
觸點類型：
公形引腳
位置數
28
間距
0.079"（2.00mm）
行數
2
行間距
0.079"（2.00mm）
安裝類型
通孔
觸點終端
壓接
緊固型
-
顏色
黑
特點
-
包裝
散裝
請注意
不提供觸點
相關產品
H11367-ND - CONN TERM 24-28AWG CRIMP TINH11367CT-ND - CONN TERM 24-28AWG CRIMP TINH11367TR-ND - CONN TERM 24-28AWG CRIMP TINH2612CT-ND - CONN TERM 24-28AWG CRIMP TINH2612-ND - CONN TERM 24-28AWG CRIMP TINH2612TR-ND - CONN TERM 24-28AWG CRIMP TIN
其它名稱
*DF4-28DP-2CH2608
