ADVANCED INFORMATION
Video Amplifier
DEVICE DESCRIPTION
The ZXFV202 is a single high speed amplifier designed
for video and other high speed applications. Packaged
in a small SOT23-5 it is ideally suited to applications
where space is at a premium. In applications where
cross talk is critical this part provides better isolation
than dual or quad devices.
It f e at u res l ow d i f fer e nt ia l g ai n a nd p h a se
p er f or mance. H i gh o ut pu t d ri v e c a p a b il it y
compliments this part for use in video applications.
FEATURES AND BENEFITS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
-3dB bandwidth 300MHz
Slew rate 400V/碌s
Differential gain 0.01%
Differential phase 0.01擄
Output current 40mA
Characterised up to 400pF load
鹵5 Volt supply
Supply current 7mA
SOT23-5 package
ZXFV202
CONNECTION DIAGRAM
APPLICATIONS
Video gain stages
CCTV buffer
Video distribution
RGB buffering
High frequency instrumentation
Cable Driving
Radar Imaging
Medical Imaging
OUT
V-
+IN
1
-
+
5
V+
鈥?/div>
-IN
ORDERING INFORMATION
PART NUMBER
ZXFV202E5TA
ZXFV202E5TC
CONTAINER
Reel 7鈥?/div>
Reel 13鈥?/div>
INCREMENT
3000
10000
TARGET - FEB 2001
1
