ZX5T853G

100V NPN LOW SAT MEDIUM POWER LOW SATURATION TRANSISTOR

IN SOT223

SUMMARY

CEO

= 100V : R

SAT

= 36m ; I

= 6A

DESCRIPTION

Packaged in the SOT223 outline this new 5

generation low saturation 100V NPN

transistor offers extremely low on state losses making it ideal for use in DC-DC

circuits and various driving and power management functions.

FEATURES

鈥?/div>

6 amps continuous current

鈥?/div>

Up to 10 amps peak current

鈥?/div>

Very low saturation voltages

SOT223

APPLICATIONS

鈥?/div>

Motor driving

鈥?/div>

Line switching

鈥?/div>

High side switches

鈥?/div>

Subscriber line interface cards (SLIC)

ORDERING INFORMATION

DEVICE

ZX5T853GTA

ZX5T853GTC

REEL

SIZE

7鈥?/div>

13鈥?/div>

TAPE

WIDTH

12mm

embossed

QUANTITY PER

REEL

1000 units

4000 units

PINOUT

DEVICE MARKING

鈥?/div>

X5T853

TOP VIEW

ISSUE 2 - SEPTEMBER 2003

SEMICONDUCTORS
