ZX5T851A

60V NPN LOW SATURATION MEDIUM POWER TRANSISTOR IN E-LINE

SUMMARY

CEO

= 60V : R

SAT

= 34m ; I

= 4.5A

DESCRIPTION

Packaged in the E-line outline this new 5th generation low saturation 60V NPN

transistor offers extremely low on state losses making it ideal for use in DC-DC

circuits and various driving and power management functions.

FEATURES

鈥?/div>

Extemely low equivalent on-resistance;

SAT

= 34m at 5A

鈥?/div>

4.5 amps continuous current

鈥?/div>

Up to 15 amps peak current

鈥?/div>

Very low saturation voltages

E-LINE

APPLICATIONS

鈥?/div>

Emergency lighting circuits

鈥?/div>

Motor driving (including DC fans)

鈥?/div>

Solenoid, relay and actuator drivers

鈥?/div>

DC modules

鈥?/div>

Backlight inverters

ORDERING INFORMATION

DEVICE

ZX5T851ASTOA

ZX5T851ASTZ

QUANTITY

2000 units / reel

2000 units / carton

DEVICE MARKING

鈥?/div>

X5T851

PINOUT

ISSUE 1 - NOVEMBER 2003

SEMICONDUCTORS
