PRECISION 2.5 VOLT LOW KNEE CURRENT
VOLTAGE REFERENCE
ISSUE 3 - MARCH 1998
DEVICE DESCRIPTION
The ZRC250 uses a bandgap circuit design to
achieve a precision micropower voltage
reference of 2.5 volts. The device is available
in small outline surface mount packages,
ideal for applications where space saving is
important, as well as packages for through
hole requirements.
The ZRC250 design provides a stable voltage
without an external capacitor and is stable
with capacitive loads. The ZRC250 is
recommended for operation between 20碌A(chǔ)
and 5mA and so is ideally suited to low
power and battery powered applications.
Excellent performance is maintained to an
absolute maximum of 25mA, however the
rugged design and 20 volt processing allows
the reference to withstand transient effects
and currents up to 200mA. Superior
switching capability allows the device to
reach stable operating conditions in only a
few microseconds.
FEATURES
ZRC250
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Small outline SOT23 and SO8 packages
TO92 style packages
No stabilising capacitor required
Low knee current, 15碌A(chǔ) typical
Typical T
C
30ppm/擄C
Typical slope resistance 0.4鈩?/div>
鹵
3, 2 and 1% tolerance
Industrial temperature range
Operating current 20碌A(chǔ) to 5mA
Transient response, stable in less than
10碌s
Optional extended current range
APPLICATIONS
Battery powered and portable
equipment.
Instrumentation.
Test equipment.
SCHEMATIC DIAGRAM
V
R
G
nd
4-247
