ZNI1000
TEMPERATURE SENSOR
DESCRIPTION
The ZNI1000 is a Ni thin film Resistance Temperature Detector (RTD), specified to
DIN 43760. The high temperature coefficient offers higher signal outputs than other
RTD鈥檚, which results in higher accuracy with smaller temperature changes.
FEATURES
鈥?/div>
Resistance at 0 C: 1000
鈥?/div>
SOT23 package
鈥?/div>
Available on 8mm tape
SOT23
APPLICATIONS
鈥?/div>
Automotive Electronic
鈥?/div>
Circuit Protection
鈥?/div>
Temperature compensation
鈥?/div>
Temperature measurement
PINOUT
ORDERING INFORMATION
DEVICE
ZNI1000TA
ZNI1000TC
REEL
SIZE
7鈥?/div>
13鈥?/div>
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000 units
10000 units
Top View
DEVICE MARKING
鈥?/div>
ZNI
Pin 1 - Ni1000
Pin 2 - Ni1000
Pin 3 - need a good thermal
contact for a short response
time
ISSUE 1 - AUGUST 2002
1
