ZL40514LCF Datasheet

  • ZL40514LCF

  • Dual Output DVD and CD 4 Channel Laser Diode Drivers

  • 1269.56KB

  • 30頁

  • ZARLINK   ZARLINK

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ZL40510/14
Dual Output DVD and CD
4 Channel Laser Diode Drivers
Data Sheet
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Single 5 V supply (鹵10%)
150 mA low-noise read channel with 100 x
current gain
Three 500 mA write channels with 240 x gain
Combined channel output 700 mA
Dual output for DVD/CD laser
Rise and fall times 1 ns typical
Oscillator, 500 MHz, 100 mA with external
resistor control of frequency and amplitude
Power Up/Down control
LVDS control signals
> 2 kV ESD
Low R
th
QFN package
Contact Zarlink for available Custom Gain and
Input Impedance options
Ordering Information
ZL40510LCE
ZL40510LCF
ZL40514LCE
ZL40514LCF
(tubes) 24 lead QFN
(tape and reel) 24 lead QFN
(tubes) 24 lead QFN
(tape and reel) 24 lead QFN
February 2005
-40擄C to +85擄C
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
DVD鹵RW/RAM
DVD鹵R
CD-RW
CD-R
Write optical drives
Laser Diode current switch
Supports double density DVD
19
20
21
PWR_UP
INR
IN2
GND
GND
VCC_A
OUTA
18
17
22
23
IN3
IN4
GND
GND 16
OUTB
VCC_B
15
14
24
1
2
3
4
5
6
GND
GND_IN
EN2
/EN2
EN3
/EN3
EN4
/EN4
VCC_IN
7
OSCEN
8
RFA
RFB
9 10
RSA
RSB
SELA
13
11 12
Figure 1 - Functional Block Diagram
1
Zarlink Semiconductor Inc.
Zarlink, ZL and the Zarlink Semiconductor logo are trademarks of Zarlink Semiconductor Inc.
Copyright 2004-2005, Zarlink Semiconductor Inc. All Rights Reserved.
