ZL40120

Low Power, Current Feedback

Quad Operational Amplifier

Data Sheet

Features

鈥?/div>

280MHz small signal bandwidth

1100V/碌s slew rate

3.3mA/channel static supply current

60Mhz gain flatness to +/- 0.1dB

14 pin SOIC

Ordering Information

ZL40120/DCA

ZL40120/DCB

(tubes) 14 lead SOIC

(tape and reel) 14 lead SOIC

April 2003

-40擄C to +85擄C

The 280MHz Av=+1V/V small signal bandwidth and

1100V/碌s slew rate make the device an excellent

solution for component video applications such as

driving RGB signals down significant cable lengths.

Other applications which may take advantage of the

ZL40120 dynamic performance features and matched

amplifiers include low cost high order active filters and

twisted pair driver/receivers.

Applications

鈥?/div>

Video switchers/routers

Video line drivers

Twisted pair driver/receiver

Active filters

Cable drivers

Description

The ZL40120 is a low power, quad, current feedback

operational amplifier offering high performance at a low

cost. The device provides a very high output current

drive capability of 65mA while requiring only 3.3mA of

static supply current per channel. This feature makes

the ZL40120 the ideal choice where a high density of

high speed devices is required.

Out_1

14 Out_4

13 In_n_4

In_n_1 2

In_p_1 3

V+ 4

In_p_2 5

12 In_p_4

ZL40120

11 V-

10 In_p_3

9 In_n_3

8 Out_3

In_n_2 6

Out_2 7

Figure 1 - Functional Block Diagram and Pin Connection
