SM-8 BIPOLAR TRANSISTOR H-BRIDGE

PRELIMINARY DATA SHEET ISSUE B JULY 1997

FEATURES

* Compact package

* Low on state losses

* Low drive requirements

* Operates up to 40V supply

* 2 Amp continuous rating

PARTMARKING DETAIL 聳 ZHB6790

ZHB6790

SM-8

(8 LEAD SOT223)

ABSOLUTE MAXIMUM RATINGS.

PARAMETER

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Peak Pulse Current

Continuous Collector Current

SYMBOL

V

CBO

V

CEO

V

EBO

I

CM

I

C

NPNs

50

40

5

6

2

PNPs

-50

-40

-5

-6

-2

UNIT

V

V

V

A

A

擄C

Operating and Storage Temperature Range T

j

:T

stg

-55 to +150

SCHEMATIC DIAGRAM

E1, E4

CONNECTION DIAGRAM

C

1,

C

2

B1

Q1

Q4

C1, C2

C3, C4

B2

Q2

Q3

B3

B4

B

1

B

2

E

2

,E

3

B

3

5

E

1

,E

4

C

3

,C

4

B

4

6

7

E2, E3

8

1

2

3

4
