XRD54L08/L10/L12

May 2000-2

3V, Low Power, Voltage Output

Serial 8/10/12-Bit DAC Family

FEATURES

D

8/10/12-Bit Resolution

D

Operates from a Single 3V Supply

D

Buffered Voltage Output: 13ms Typical Settling Time

D

145mW Total Power Consumption (typ)

D

Guaranteed Monotonic Over Temperature

D

Flexible Output Range: 0V to V

DD

D

8 Lead SOIC and PDIP Package

D

Power On Reset

D

Serial Data Output for Daisy Chaining

APPLICATIONS

D

Digital Calibration

D

Battery Operated Instruments

D

Remote Industrial Devices

D

Cellular Telephones

D

Motion Control

D

VXCO Control

D

Comparator Level Setting

GENERAL DESCRIPTION

The XRD54L08/L10/L12 are low power, voltage output

digital-to-analog converters (DAC) for +3V power supply

operation. The parts draw only 50mA of quiescent current

and are available in both an 8-lead PDIP and SOIC

package.

The XRD54L08/L10/L12 have a 3 wire serial port with an

output allowing the user to daisy chain several of them

together. The serial port will support both Microwiret,

SPIt, and QSPIt standards.

The outputs of the XRD54L08/L10/L12 are set at a gain of

+2. The output short circuit current is 7mA typical.

ORDERING INFORMATION

Part No.

XRD54L08AID

XRD54L08AIP

XRD54L10AID

XRD54L10AIP

XRD54L12AID

XRD54L12AIP

Package

8 Lead 150 Mil JEDEC SOIC

8 Lead 300 Mil PDIP

8 Lead 150 Mil JEDEC SOIC

8 Lead 300 Mil PDIP

8 Lead 150 Mil JEDEC SOIC

8 Lead 300 Mil PDIP

Operating

Temperature Range

-40擄C to +85擄C

-40擄C to +85擄C

-40擄C to +85擄C

-40擄C to +85擄C

-40擄C to +85擄C

-40擄C to +85擄C

Rev. 1.30

E2000

EXAR Corporation, 48720 Kato Road, Fremont, CA 94538

z

(510) 668-7000

z

(510) 668-7017
