2.5 Gbps PIN-TIA module
XPD0250CT-001
F
EATURES
Wide dynamic range, typically 6碌W to 1.7mW (p-p)
Differential transimpedance of 4銖€
Bandwidth from DC to 1.9GHz
Differential outputs
On-chip Automatic Gain Control(AGC)
Single supply voltage 3.3V
Remains linear up to 1.7mW(p-p) input current(unclipped)
AGC C
HARACTERISTICS
The XPD0250CT-001 can handle input optical power from 6碌W to 1.7mW which is equivalent to a
dynamic range of 49dB. At low input optical power, the transimpedance gain ZT must be high to
obtain enough output voltage, and the noise should be low enough to guarantee a minimum bit error
rate. The transimpedance is regulated from 4
銖€
at low input optical power (Po<30碌W) to 80鈩t
high power (Po =1.7mW).
A
PPLICATIONS
Digital fiber optic receiver in short, medium and long haul optical telecommunications
transmission systems or in high speed data networks
Wide-band RF gain block
E
LECTRICAL
C
HARACTERISTICS (T
C
= 25鈩?
Parameter
Power supply voltage
Power supply current
Photodiode bias voltage*
Transimpedance
3dB Bandwidth
Transimpedence gain deviation
Electrical return loss
Responsivity
Output impedence
Symbol
V
CC
I
CC
V
PD
Z
T
f
3dB
螖Z
T
L
E
R
Z
O
Test Condition
-
-
-
RL=50鈩? measured
differenctially, AC coupled
Min.
3.0
3.3
Typ.
3.3
26
Max.
3.3
37
5
Unit
V
mA
V
K鈩?/div>
GHz
4
1.7
1.9
2
-10
0.85
50
Pin=-10dBm
f=1MHz to 1.8GHz
-
位
= 1550nm
-
dB
dB
A/W
鈩?/div>
* Photodiode bias is necessary only for 5 pin type module.
XL Photonics, Inc.
