Recommended System Management
Alternative: X4163
16K
X24C16
Serial EEPROM
2048 x 8 Bit
FEATURES
鈥?2.7V to 5.5V power supply
鈥?Low power CMOS
鈥擜ctive read current less than 1 mA
鈥擜ctive write current less than 3 mA
鈥擲tandby current less than 1碌A(chǔ)
鈥?Internally organized 2048 x 8
鈥?2-wire serial interface
鈥擝idirectional data transfer protocol
鈥?Sixteen byte page write mode
鈥擬inimizes total write time per byte
鈥?Self-timed write cycle
鈥擳ypical write cycle time of 5 ms
鈥?High reliability
鈥擡ndurance: 1,000,000 cycles
鈥擠ata retention: 100 years
鈥?Packages
鈥?4-lead TSSOP
鈥?-lead SOIC
DESCRIPTION
BLOCK DIAGRAM
(8) V
CC
(4) V
SS
(7) TEST
(5) SDA
(6) SCL
(3) A2
(2) A1
(1) A0
or
ic
X
REV 1.1.1 12/8/00
In
Sy t
st eg F
em ra or
te a
M d
an S mo
ag olu re
em tio
en n u
t P se
ro
du
ct
s
START Cycle
H.V. Generation
Timing
& Control
START
STOP
Logic
Control
Logic
Slave Address
Register
+Comparator
LOAD
INC
X Dec
EEPROM
128 X 128
Word
Address
Counter
R/W
Y Dec
8
CK
PIN
D
OUT
ACK
Data Register
D
OUT
The X24C16 is a CMOS 16,384 bit serial EEPROM,
internally organized 2048 X 8. The X24C16 features a
serial interface and software protocol allowing opera-
tion on a simple two wire bus.
The X24C16 is fabricated with Xicor鈥檚 advanced
CMOS Textured Poly Floating Gate Technology.
The X24C16 utilizes Xicor鈥檚 proprietary Direct Write
鈩?/div>
cell providing a minimum endurance of 1,000,000
cycles and a minimum data retention of 100 years.
www.xicor.com
Characteristics subject to change without notice.
1 of 14
