24-bit, 192kHz Stereo CODEC
DESCRIPTION
The WM8591 is a high performance, stereo audio CODEC with
single-ended inputs and differential outputs. It is ideal for
surround sound processing applications for home hi-fi, DVD-
RW and other audio visual equipment.
The stereo 24-bit multi-bit sigma delta ADC has programmable
gain with limiting control. Digital audio output word lengths from
16-32 bits and sampling rates from 32kHz to 96kHz are
supported.
A stereo multi-bit sigma delta DAC is used with digital audio
input word lengths from 16-32 bits and sampling rates from
32kHz to 192kHz.
The WM8591 supports fully independent sample rates for the
ADC and DAC. The audio data interface supports I
2
S, left
justified, right justified and DSP formats.
The device is controlled in software via a 2-wire serial interface
which provides access to all features including volume controls,
mutes, and de-emphasis facilities. The device is available in a
28-pin SSOP package.
WM8591
FEATURES
鈥?/div>
Audio Performance
鈭?/div>
110dB SNR (鈥楢鈥?weighted @ 48kHz) DAC
鈭?/div>
102dB SNR (鈥楢鈥?weighted @ 48kHz) ADC
DAC Sampling Frequency: 32kHz 鈥?192kHz
ADC Sampling Frequency: 32kHz 鈥?96kHz
Stereo ADC input analogue gain adjust from +24dB to 鈥?1dB in
0.5dB steps
ADC digital gain from -21.5dB to -103dB in 0.5dB steps
Programmable Limiter on ADC input.
Stereo DAC with differential analogue line outputs.
2-wire Serial Control Interface
Master or Slave Clocking Mode
Programmable Audio Data Interface Modes
鈭?/div>
I
2
S, Left, Right Justified or DSP
鈭?/div>
16/20/24/32 bit Word Lengths
4.5V to 5.5V Analogue, 2.7V to 3.6V Digital supply Operation
28-pin SSOP Package
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
APPLICATIONS
BLOCK DIAGRAM
鈥?/div>
鈥?/div>
Surround Sound AV Processors and Hi-Fi systems
DVD-RW
WOLFSON MICROELECTRONICS plc
w :: www.wolfsonmicro.com
Product Preview, May 2005, Rev 1.0
Copyright
餂?005
Wolfson Microelectronics plc
