RFI CERAMIC DISC CAPACITORS

Suppression Capacitors

Class X1 AC 440 V

Class Y2 AC 250 V

Design:

Disc capacitor with epoxy coating

Rated Voltage U

鈬?/div>

AC 440 V; 50 Hz

鈬?/div>

AC 250 V; 50/60 Hz

Test Voltage U

Component test:

AC 2500 V / 50 Hz, 2 s

As repeated voltage test admissible

only once at: AC 2250 V / 50 Hz, 2 s

Random Sampling Test:

AC 2500 V / 50 Hz, 60 s

Voltage Proof of Coating:

AC 2500 V / 50 Hz, 60 s

Dissipation Factor tan未:

鈮?/div>

25 x 10

鈥?

Insulation Resistance R

for C

鈮?/div>

0,33 碌F

鈮?/div>

6 x 10

鈩?/div>

Temperature Characteristic acc.

to EN 130 700:

2E3

Category Temperature Range

未

(鈥?0 . . . + 85) 潞C acc. to IEC 384-14/1

(鈥?0 . . . + 125) 潞C acc. to IEC 384-14/2

Climatic Testing Class acc.

to EN 60068-1:

40/085/21 acc. to IEC 384-14/1

40/125/21 acc. to IEC 384-14/2

Coating:

Epoxy, dipped, insulating, flame

retarding (UL 94V0)

Important:

Minimum thickness of 0,4 mm for the

epoxy coating is now confirmed by the

VDE-approval board in Germany

Taping:

on request

Special Lead Configurations:

on request

Marking:

鈮?/div>

10 mm

additional on the label:

all approval marks

WKO

Dimensions in mm

Marking:

鈮?/div>

9 mm

additional on the label:

all approval marks

Soldering Recommendations:

When soldering this component to a PC board, the

solder heat resistance specification of the capacitor

must not be exceeded.

Subjecting this component to excessive heating could

melt the internal solder junction and may cause

thermal stress that can crack the ceramic element.

In order to keep a sufficient distance between solder

wave and the capacitor element we recommend to

use capacitor styles with crimped leads.
