W78C54P-40 Datasheet

  • W78C54P-40

  • 8-BIT MICROCONTROLLER

  • 22頁

  • WINBOND

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

W78C54
8-BIT MICROCONTROLLER
GENERAL DESCRIPTION
The W78C54 is a derivative of the W78C52 microcontroller family that provides extended internal
ROM. The chip has 16K bytes of mask ROM and 256 bytes of RAM.
This device provides an enhanced architecture that makes it more powerful and suitable for a variety
of applications for general control systems. It provides on-chip 16KB mask ROM to accommodate
large program codes, 256-bytes of non-volatile on-chip RAM, four 8-bit I/O ports, one 4-bit I/O port,
three 16-bit timer/counters, eight sources with two-level interrupt structures, and on-chip oscillator
clock circuits.
FEATURES
鈥?/div>
DC to 40 MHz extensive operating frequency
鈥?/div>
256-byte on-chip scratch pad RAM
鈥?/div>
16K-byte on-chip mask ROM
鈥?/div>
64K-byte address space for external Program Memory
鈥?/div>
64K-byte address space for external Data Memory
鈥?/div>
Three 16-bit timer/counters
鈥?/div>
Four 8-bit bit-addressable I/O ports
鈥?/div>
One extra 4-bit bit-addressable I/O port, additional INT2/ INT3
(Available on 44-pin PLCC/QFP package)
鈥?/div>
Eight-source, two priority-level interrupts
鈥?/div>
Low EMI emission mode
鈥?/div>
Built-in programmable power-saving modes - Idle mode & Power-down mode
鈥?/div>
Packages:
鈭?/div>
DIP 40: W78C54-16/24/40
鈭?/div>
PLCC 44: W78C54P-16/24/40
鈭?/div>
QFP 44: W78C54F-16/24/40
鈭?/div>
TQFP 44: W78C54M-16/24/40
-1-
Publication Release Date: December 1997
Revision A2
