W29C040-90 Datasheet

  • W29C040-90

  • EEPROM|FLASH|512KX8|CMOS|DIP|32PIN|PLASTIC

  • 337.97KB

  • 24頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

W29C040
512K
脳
8 CMOS FLASH MEMORY
GENERAL DESCRIPTION
The W29C040 is a 4-megabit, 5-volt only CMOS page mode Flash Memory organized as 512K
脳
8
bits. The device can be written (erased and programmed) in-system with a standard 5V power supply.
A 12-volt V
PP
is not required. The unique cell architecture of the W29C040 results in fast write (erase/
program) operations with extremely low current consumption (compared to other comparable 5-volt
flash memory products.) The device can also be erased and programmed by using standard EPROM
programmers.
FEATURES
鈥?/div>
鈥?/div>
Single 5-volt write (erase and program)
operations
Fast page-write operations
鈭?/div>
256 bytes per page
鈭?/div>
Page write (erase/program) cycle: 5 mS
(typ.)
鈭?/div>
Effective byte-write (erase/program) cycle
time: 19.5
碌S
鈭?/div>
Optional software-protected data write
鈥?/div>
鈥?/div>
Software and hardware data protection
Low power consumption
鈭?/div>
Active current: 25 mA (typ.)
鈭?/div>
Standby current: 20
碌A(chǔ)
(typ.)
鈥?/div>
鈥?/div>
Automatic write (erase/program) timing with
internal V
PP
generation
End of write (erase/program) detection
鈭?/div>
Toggle bit
鈭?/div>
Data polling
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Fast chip-erase operation: 50 mS
Two 16 KB boot blocks with lockout
Page write (erase/program) cycles: 50K (typ.)
Read access time: 70/90/120 nS
Ten-year data retention
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Latched address and data
All inputs and outputs directly TTL compatible
JEDEC standard byte-wide pinouts
Available packages: 32-pin 600 mil DIP, TSOP
and PLCC
-1-
Publication Release Date: May 6, 2002
Revision A9
