Product Data Sheet
VS-500A
Voltage Controlled Saw Oscillator
Features
鈥?Output Frequency @ 155 MHz to 1 GHz
鈥?Low jitter, 1.5ps rms (typical) for 622.080 MHz, 3ps
rms (typical) for 155 MHz
鈥?J-type package -
smallest 622.080 MHz package
available
鈥?Ideal for clock smoothing, frequency translation,
clock and data retiming applications
鈥?10K ECL, PECL logic levels with fast transition times
鈥?Complementary outputs
鈥?Low profile, surface mount package
鈥?Output disable feature
Applications
鈥?OC192/OC48/OC12/OC3 Clock Smoothing
鈥?STS96/STS48/STS12/STS3/STS1 Clock Smoothing
鈥?Frequency Translation
Description
The VS 500A is a SAW stabilized, voltage controlled
oscillator that operates at the fundamental frequency
of the internal SAW filter. This filter is a high stability,
high-Q quartz device that enables the circuit to
achieve low phase jitter performance over a wide
operating temperature range. The oscillator is housed
in a hermetically sealed J-lead surface mount
package. It has an output disable to facilitate on-
board testing.
