HIGH PRECISION TEST and
MEASUREMENT INSTRUMENTS
DESCRIPTION
VRE117 Series Precision Voltage References
provide ultrastable +3.000V (VRE117), -3.000V
(VRE118) and 鹵3.000V (VRE119) outputs with
鹵0.200 mV initial accuracy and temperature
coefficient as low as 0.6 ppm/擄C over the full
military temperature range. This improvement in
accuracy is made possible by a unique,
proprietary
multipoint
laser
compensation
technique developed by Thaler Corporation.
Significant improvements have been made in
other performance parameters as well, including
initial accuracy, warm-up drift, line regulation, and
long-term stability, making the VRE117 series the
most accurate and stable 3.0V reference
available.
SELECTION GUIDE
Type
VRE117C
VRE117CA
VRE117M
VRE117MA
VRE118C
VRE118CA
VRE118M
VRE118MA
VRE119C
VRE119CA
VRE119M
VRE119MA
Output
+3.0V
+3.0V
+3.0V
+3.0V
-3.0V
-3.0V
-3.0V
-3.0V
鹵3.0V
鹵3.0V
鹵3.0V
鹵3.0V
Temperature
Operating Range
-25擄C to +85擄C
-25擄C to +85擄C
-55擄C to +125擄C
-55擄C to +125擄C
-25擄C to +85擄C
-25擄C to +85擄C
-55擄C to +125擄C
-55擄C to +125擄C
-25擄C to +85擄C
-25擄C to +85擄C
-55擄C to +125擄C
-55擄C to +125擄C
Max. Volt
Deviation
200 碌V
100 碌V
400 碌V
200 碌V
200 碌V
100 碌V
400 碌V
200 碌V
200 碌V
100 碌V
400 碌V
200 碌V
VRE117/118/119 devices are available in two
operating temperature ranges, -25擄C to +85擄C
and -55擄C to +125擄C, and two performance
grades. All devices are packaged in 14-pin hermetic ceramic packages for maximum long-term stability. "M"
versions are screened for high reliability and quality.
Superior stability, accuracy, and quality make these references ideal for precision applications such as A/D
and D/A converters, high-accuracy test and measurement instrumentation, and transducer excitation.
VRE117DS REV. C NOV 2000
