rev.
page
date
1 of 3
12/2007
PART NUMBER:
VIBLT-SMT series
DESCRIPTION:
DC/DC converter
description
Designed for applications where a
group of polar power supplies are
isolated from the input power sup-
ply in a distributed power supply
system on a circuit board.
features
路
SMD package
路temperature range: -40擄C~+85擄C
路1K Vdc isolation
路internal SMD construction
路short circuit protection
路industry standard pinout
路no heatsink required
路no external component required
路RoHS compliant
model
number
VIBLT1-S5-S5-SMT
VIBLT1-S5-S9-SMT
VIBLT1-S5-S12-SMT
VIBLT1-S5-S15-SMT
VIBLT1-S12-S5-SMT
VIBLT1-S12-S9-SMT
VIBLT1-S12-S12-SMT
VIBLT1-S12-S15-SMT
VIBLT1-S15-S5-SMT
VIBLT1-S15-S9-SMT
VIBLT1-S15-S12-SMT
VIBLT1-S15-S15-SMT
VIBLT1-S24-S5-SMT
VIBLT1-S24-S9-SMT
VIBLT1-S24-S12-SMT
VIBLT1-S24-S15-SMT
input voltage
nominal
range
5 Vdc
5 Vdc
5 Vdc
5 Vdc
12 Vdc
12 Vdc
12 Vdc
12 Vdc
15 Vdc
15 Vdc
15 Vdc
15 Vdc
24 Vdc
24 Vdc
24 Vdc
24 Vdc
4.75~5.25 Vdc
4.75~5.25 Vdc
4.75~5.25 Vdc
4.75~5.25 Vdc
11.4~12.6 Vdc
11.4~12.6 Vdc
11.4~12.6 Vdc
11.4~12.6 Vdc
12.8~15.2 Vdc
12.8~15.2 Vdc
12.8~15.2 Vdc
12.8~15.2 Vdc
22.8~25.2 Vdc
22.8~25.2 Vdc
22.8~25.2 Vdc
22.8~25.2 Vdc
output
voltage
5 Vdc
9 Vdc
12 Vdc
15 Vdc
5 Vdc
9 Vdc
12 Vdc
15 Vdc
5 Vdc
9 Vdc
12 Vdc
15 Vdc
5 Vdc
9 Vdc
12 Vdc
15 Vdc
output current
max.
min.
150 mA
111 mA
83 mA
67 mA
150 mA
111 mA
83 mA
67 mA
150 mA
111 mA
83 mA
67 mA
150 mA
111 mA
83 mA
67 mA
15 mA
12 mA
9 mA
7 mA
15 mA
12 mA
9 mA
7 mA
15 mA
12 mA
9 mA
7 mA
15 mA
12 mA
9 mA
7 mA
efficiency (typ)
69%
70%
71%
72%
69%
70%
71%
72%
69%
70%
71%
72%
69%
70%
71%
72%
OUTPUT SPECIFICATIONS
item
output power
line regulation
load regulation
output voltage accuracy
temperature drift
output ripple
output noise
switching frequency
test conditions
for Vin change of 5%
10% to 100% full load
@ full load
@ 100% load
20 MHz bandwidth
20 MHz bandwidth
full load, nominal input
min.
0.1
typ.
max.
1
鹵0.3
1
鹵3
0.03
20
100
units
W
%
%
%
%/擄C
mVp-p
mVp-p
KHz
10
50
100
