NON-ISOLATED DC/DC CONVERTERS
3.3V Input / 0.9V 鈥?2.5V Output / 10A
V7PB-10C Series
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Nonisolated
Industry standard footprint
Fixed frequency
High efficiency means less power dissipation
Excellent thermal performance
Optimized for cost
Remote on/off
Remote sense
Undervoltage lockout (UVLO)
Over current and short circuit protection
Industrial temperature range
POWER PRODUCTS
BP03V7PB-10C
Description
The Bel V7PB-10C modules are a series of non-isolated, step down DC/DC power converters that operate from a nominal
3.3V source. These converters are available in a range of output voltages from 0.9V to 2.5V. They are packaged in a compact,
SIP package rated at 10A. Standard features include remote on/off, over current and short circuit protection, output voltage
adjust and industrial temperature range (-40擄 to +85擄 C). The output is closely regulated and the efficiency is typically 95% @
2.5V output at full load. These products may be used almost anywhere low voltage silicon is employed and a 3.3V source is
available. Typical applications include file servers, routers, line cards and other computing and communications equipment.
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Distributed power architectures
Data networking equipment
Telecommunications
Computers and peripherals
Part Number Selection
Output
Voltage
2.5V
1.8V
1.5V
1.2V
0.9V
Input
Voltage
3.3V
3.3V
3.3V
3.3V
3.3V
Max. Output
Current
10A
10A
10A
10A
10A
Max. Output
Power
25W
18W
15W
12W
9W
Typical
Efficiency
95%
92.5%
91.5%
90%
87%
Part Number
Remote Sense
Active Low
V7PB-10C25L
V7PB-10C18L
V7PB-10C15L
V7PB-10C12L
V7PB-10C09L
Part Number
Remote Sense
Active High
V7PB-10C25S
V7PB-10C18S
V7PB-10C15S
V7PB-10C12S
V7PB-10C09S
漏2003 Bel Fuse Inc.
Specifications subject to change without notice. 09.03
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
