Nonisolated
Industry standard pinout with shorter package length
Fixed frequency
High efficiency
Excellent thermal performance
Low cost
Remote on/off
Undervoltage lockout
Over current and short circuit protection
POWER PRODUCTS
BP01V7PB-06B
Description
The Bel V7PB-06B series modules are non-isolated, step down DC/DC power converters that operate from a nominal 5V
source. These converters are available in a range of output voltages from 1.5V to 3.3V. They are packaged in an industry
standard single-in-line footprint and provide a maximum 6A output. Standard features include remote on/off, over current
protection and output voltage adjust. Optional features include remote sense and industrial temperature range. These
products may be used almost anywhere low-voltage silicon is employed and a 5V source is available. Typical applications
include file servers, routers, line cards and other computing and communications equipment.
Applications
鈥?/div>
鈥?/div>
鈥?/div>
Telecommunications
Networking
Computers and peripherals
Options
鈥?/div>
鈥?/div>
Remote sense
Industrial temperature range
Part Number Selection
Output
Voltage
3.3V
2.5V
1.5V
Input
Voltage
5V
5V
5V
Max. Output
Current
6A
6A
6A
Max. Output
Power
19.8W
15.0W
9.0W
Typical
Efficiency
94%
91%
87%
Part Number
V7PB-06B330
V7PB-06B250
V7PB-06B150
Part Number
Remote Sense Option
V7PB-06B33S
V7PB-06B25S
V7PB-06B15S
漏2002 Bel Fuse Inc. Specifications subject to change without notice. 01.02
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
page 1
