300Vin / 2Vout / 100Watts
DC-DC Converter Module
Model Number V300B2C100A*
DC input range: 180 - 375V
Input surge withstand: 400V for 100ms
DC output: 2V
Programmable output: 10 to 110%
Regulation: 鹵0.3%
Efficiency: 71.0%
Maximum operating temperature:
100擄C at full load
Power density: 100W/cubic inch
Height above board: 0.43 in. (10,9 mm)
Parallelable, with N+M fault tolerance
Low noise ZCS/ZVS architecture
Typical Applications:
off-line systems,
distributed power and electric vehicles
Shown actual size:
2.28 x 2.2 x 0.5 in
57,9 x 55,9 x 12,7 mm
Product Overview
Absolute Maximum Ratings
This DC-DC converter module uses
second generation power processing, control
and packaging technologies to provide the
Parameter
Rating
performance, flexibility and cost effectiveness
+In to 鈥揑n voltage
-0.5 to +375
expected of a mature Power Component.
For example, a plated-cavity core transformer
+In to 鈥揑n voltage
400
couples widely separated primary and
PC to 鈥揑n voltage
-0.5 to +7.0
secondary windings, resulting in low in-to-
PR to 鈥揑n voltage
-0.5 to +7.0
out parasitic capacitance and noise.
+Out to 鈥揙ut voltage
-0.5 to +5.0
High frequency ZCS/ZVS switching,
advanced power semiconductor packaging
+Sense to 鈥揙ut voltage
-0.5 to +5.0
and thermal management provide high
鈥揝ense to 鈥揙ut voltage
1.0
power density with low temperature
SC to 鈥揙ut voltage
-0.5 to +1.5
gradients. Extensive use of silicon
Isolation voltage (in to out)
3000
integration results in 1/3 the part count
Isolation voltage (in to base)
1550
of a first generation converter.
* Part Numbering
Isolation voltage (out to base)
Storage temperature (C-Grade)
Operating temperature (C-Grade)
Pin
Style
Base-
plate
Unit
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vrms
Vrms
Vrms
擄C
擄C
擄F (擄C)
擄F (擄C)
in-lbs (N-m)
Notes
<100ms
500
-40 to +125
-20 to +100
500 (260)
750 (390)
5 (.57)
See part numbering chart on this
page for other product grades.
V 300 B 15 C 250 A
Input
Voltage
A = Maxi
B = Mini
C = Micro
Output
Voltage
Output
Power
Baseplate
<5 sec; wave solder
<7 sec; hand solder
6 each, # 4-40 or M3
Pin soldering temperature
Pin soldering temperature
Mounting torque
Product Grade Temperatures (擄C)
Grade Storage
Operating
C =
-
40 to +125
-
20 to +100
T =
-
40 to +125
-
40 to +100
H =
-
55 to +125
-
40 to +100
M =
-
65 to +125
-
55 to +100
Thermal Resistance and Capacity
Parameter
Baseplate to sink; flat, greased surface
Baseplate to sink; thermal pad (P/N 20264)
Baseplate to ambient
Baseplate to ambient; 1000 LFM
Thermal capacity
Min
Typ
0.16
0.14
8.0
1.9
83
Max
Unit
擄C/Watt
擄C/Watt
擄C/Watt
擄C/Watt
Watt-sec/擄C
For pin styles see page 6. Slotted baseplate
(style 1) requires no designator. For
threaded baseplate add a 鈥?鈥?to the end of
the part number. For thru-hole, add a 鈥?鈥?
See page 7 for dimensions.
Vicor Corporation
Tel: 800-735-6200 Fax: 978-475-6715
Data Sheet: V300B2C100A DC-DC Converter
Date: 7-01 Rev. 3
Page 1 of 8
