(5V / 3.3V)
Multimode 850 nm 1.0625 GBd Fibre Channel
1.3 Gigabit Ethernet 1x9 Transceiver
Dimensions in (mm) inches
View Z
(Lead cross section
and standoff size)
V23826-K305-C
(*)
TRX without shield
(9.79 max)
.385 max
(2) .080
Process plug
Optical
Centerline
(8.6 max)
.338 max
(0.63
鹵0.2
)
.025
鹵.008
(1
鹵0.1
)
.04
鹵.004
(
3.3
鹵0.2
)
.13
鹵.008
PC board
(3.8 max)
.150 max
(15.88
鹵0.25
)
.625
鹵.010
(0.35
鹵0.1
)
.014
鹵.004
4.875
.192
9x
(0.8
鹵0.1
)
.032
鹵.004
(0.6
鹵0.1
)
.024
鹵.004
(0.5) typ.
.020 typ.
(0.25) typ.
.010 typ.
(25.25
鹵0.05
)
.994
鹵.002
20.32
.800
Z
q
q
q
q
q
q
q
q
q
(1.4 -
0.05
) (2.8 max)
.055 -
.002
.110 max
1 2 3 4 5 6 7 8 9
(2.54)
.100
Cutout
20.32
.800
Rx
Top view
(2.05)
.081
Tx
12.7
.500
(2.54)
.100
20.32
.800
(1.9
鹵0.1
)
2x
.075
鹵.004
A
(38.6
鹵0.15
)
1.52
鹵.006
(2.5)
.098
(11 max)
.433 max
Footprint
Absolute Maximum Ratings
Exceeding any one of these values may destroy the device
immediately.
Package Power Dissipation................................................ 1.5 W
Supply Voltage (V
CC
鈥揤
EE
) 5 V .............................................. 7 V
3.3 V ........................................... 5 V
Data Input Levels (PECL) ........................................... V
CC
+0.5 V
Differential Data Input Voltage ............................................ 2.5 V
Operating Ambient Temperature ............................... 0擄 to 70擄C
Storage Ambient Temperature ............................ 鈥?0擄C to 85擄C
Soldering Conditions Temp/Time
(MIL
-STD 883C, Method 2003) ............................. 250擄C/5.5s
*) Ordering Information
Input
AC
AC
DC
AC
Output Signal detect
DC
AC
DC
AC
PECL
TTL
PECL
PECL
Voltage
5V
3.3 V
5V
3.3 V
5V
3.3 V
5V
3.3 V
Shield options
Metallized cover, forward springs
Metallized cover, backward springs
Note
1. Standard version
Part number
V23826-K305-C13
V23826-K305-C313
V23826-K305-C53
V23826-K305-C353
V23826-K305-C63
(1)
V23826-K305-C363
(1)
V23826-K305-C73
V23826-K305-C373
Add suffix to PIN
-C3
-D3
FEATURES
鈥?Compliant with Fibre Channel and Gigabit Ethernet
standard
鈥?Meets mezzanine standard height of 9.8 mm
鈥?Compact integrated transceiver unit with
鈥?VCSEL transmitter
鈥?Integrated receiver
鈥?Duplex SC receptacle
鈥?Class 1 FDA and IEC laser safety compliant
鈥?Single power supply (5 V or 3.3 V)
鈥?Signal detect indicator (PECL and TTL version)
鈥?PECL differential inputs and outputs
鈥?Process plug included
鈥?Performance exceeds FC 100-M5-SLI
鈥?Wave solderable and washable with process plug
inserted
鈥?For distances of up to 550 m on multimode fiber
Fibre Optics
DECEMBER 2000
1
2
3
4
5
6
7
8
9
