Fiber Optics

Multimode 850 nm

1.0625 Gbit/s Fibre Channel

1.3 Gigabit Ethernet 1x9 Transceiver

V23826-K305-Cxx/Cxxx

Features

鈥?Compliant with Fibre Channel and

Gigabit Ethernet standard

鈥?Meets mezzanine standard height of 9.8 mm

鈥?Compact integrated transceiver unit with

鈥?VCSEL transmitter

鈥?Integrated receiver

鈥?Duplex SC receptacle

鈥?Class 1 FDA and IEC laser safety compliant

鈥?FDA Accession No. 9520890-18

鈥?Single power supply (5 V or 3.3 V)

鈥?Signal detect indicator (PECL and TTL version)

鈥?PECL differential inputs and outputs

鈥?Process plug included

鈥?Performance exceeds FC 100-M5-SLI

鈥?Wave solderable and washable with process plug inserted

鈥?For distances of up to 550 m on multimode fiber

Part Number

V23826-K305-C13

V23826-K305-C313

V23826-K305-C53

V23826-K305-C353

V23826-K305-C63

1)

V23826-K305-C363

1)

V23826-K305-C73

V23826-K305-C373

Add Suffix to PIN

-C3

-D3

1)

File: 1159

Voltage

5V

3.3 V

5V

3.3 V

5V

3.3 V

5V

3.3 V

Signal Detect

PECL

TTL

PECL

PECL

Input

AC

AC

DC

AC

Output

DC

AC

DC

AC

Shield Options

Metallized cover, forward springs

Metallized cover, backward springs

Standard version

Data Sheet

1

2004-01-27

next
