Surge Arrester
2-Electrode-Arrester
V10-H30X
Ordering code:
B88069X4330C251
DC spark-over voltage
1) 2)
Impulse spark-over voltage
at 1 kV/碌s
- for 99 % of measured values
- typical values of distribution
Nominal impulse discharge current (wave 8/20 碌s)
Single impulse discharge current
(wave 8/20 碌s)
Nominal alternating discharge current (50 Hz, 1 s)
Alternating discharge current (50 Hz, 9 cycles)
Insulation resistance at 100 V
dc
Capacitance at 1 MHz
Arc voltage at 1 A
Glow to arc transition current
Glow voltage
Weight
Operation and storage temperature
Climatic category (IEC 60068-1)
Marking, black
3000
鹵
25
< 5000
< 4500
20
25
20
100
> 10
< 1.5
~ 30
~1
~ 200
~9
-40 ...+90
40/.90/.21
3000 YY O
3000
YY
O
- Nominal voltage
- Year of production
- Non radioactive
V
%
V
V
kA
kA
A
A
G鈩?/div>
pF
V
A
V
g
擄C
1)
2)
At delivery AQL 0.65 level II, DIN ISO 2859
In ionized mode
Terms in accordance with ITU-T Rec. K.12 and DIN 57845/VDE0845
AB E / AB PM
Page 1 of 2
Issue 03, 26.04.2002
