Standard Products
UT63M14x MIL-STD-1553A/B Bus Transceiver
Data Sheet
Sept. 1999
FEATURES
q
5-volt only operation (+10%)
q
Completely monolithic bipolar technology
q
Fit and functionally compatible to industry standard
transceiver
q
Idle low transmitter inputs and receiver outputs
q
Dual-channel 50-mil center 24-lead Flatpack
q
Dual-channel 100-mil center 36-pin DIP
q
Full military operating temperature range, -55擄C to +125擄C,
screened to QML Q or QML V requirements
q
Radiation hardened to 1.0E6 rads(Si)
q
Supports MIL-STD-1760 (UT63M145) and MIL-STD-1553
(UT63M147)
q
Standard Microcircuit Drawing (SMD) 5962-93226
available
INTRODUCTION
The monolithic UT63M14x Transceivers are complete
transmitter and receiver pairs for MIL-STD-1553A and 1553B
applications. Encoder and decoder interfaces are idle low.
The receiver section of the UT63M14x series accepts biphase-
modulated Manchester II bipolar data from a MIL-STD-1553
data bus and produces TTL-level signal data at its RXOUT and
RXOUT outputs. An external RXEN input enables or disables
the receiver outputs.
RXEN
RXOUT
RXIN
RXIN
F ILTER
and
LIMITER
THRESHOLD
REFERENCE
DRIVERS
TXOUT
COMPARE
TXOUT
TXIN
FROM ENCODER
TXIN
F ILTER
TO DECODER
RXOUT
TXIHB
Figure 1. Functional Block Diagram
1
