UT54ACS365/UT54ACTS365

Radiation-Hardened

Hex Buffers/Line Drivers with Three-State Outputs

FEATURES

radiation-hardened CMOS

- Latchup immune

High speed

Low power consumption

Single 5 volt supply

Available QML Q or V processes

Flexible package

- 16-pin DIP

- 16-lead flatpack

DESCRIPTION

The UT54ACS365 and UT54ACTS365 are non-inverting hex

buffer and line driver with three-state outputs. The output en-

ables (OE1 and OE2) control the three-state outputs. If OE1 or

OE2 is high, the outputs will be in a high impedance state. For

data, both OE1 and OE2 must be low.

The devices are characterized over full military temperature

range of -55 C to +125 C.

FUNCTION TABLE

INPUTS

OE1

L

L

X

H

OE2

L

L

H

X

A

L

H

X

X

OUTPUT

Y

L

H

Z

Z

PINOUTS

16-Pin DIP

Top View

OE1

A1

Y1

A2

Y2

A3

Y3

V

SS

1

2

3

4

5

6

7

8

16

15

14

13

12

11

10

9

V

DD

OE2

A6

Y6

A5

Y5

A4

Y4

16-Lead Flatpack

Top View

OE1

A1

Y1

A2

Y2

A3

Y3

V

SS

1

2

3

4

5

6

7

8

16

15

14

13

12

11

10

9

V

DD

OE2

A6

Y6

A5

Y5

A4

Y4

LOGIC SYMBOL

OE1

OE2

(1)

(15)

&

EN

A1

A2

A3

A4

A5

A6

(2)

(4)

(6)

(10)

(12)

(14)

(3)

(5)

(7)

(9)

(11)

(13)

Y1

Y2

Y3

Y4

Y5

Y6

Note:

1. Logic symbol in accordance with ANSI/IEEE Std 91-1984 and

IEC Publication 617-12.

211

RadHard MSI Logic
