UT54ACS245/UT54ACTS245
Radiation-Hardened
Octal Bus Transceiver with Three-State Outputs
FEATURES
Three-state outputs drive bus line directly
radiation-hardened CMOS
- Latchup immune
High speed
Low power consumption
Single 5 volt supply
Available QML Q or V processes
Flexible package
- 20-pin DIP
- 20-lead flatpack
DESCRIPTION
The UT54ACS245 and the UT54ACTS245 are non-inverting
octal bus transceivers designed for asynchronous two-way com-
munication between data buses. The control function imple-
mentation minimizes external timing requirements.
The devices allow data transmission from the A bus to the B bus
or from the B bus to the A bus depending upon the logic level
at the direction control (DIR) input. The enable input (G) dis-
ables the device so that the buses are effectively isolated.
The devices are characterized over full military temperature
range of -55 C to +125 C.
FUNCTION TABLE
ENABLE
G
L
L
H
DIRECTION
CONTROL DIR
L
H
X
OPERATION
B Data To A Bus
A Data To B Bus
Isolation
PINOUTS
20-Pin DIP
Top View
DIR
A1
A2
A3
A4
A5
A6
A7
A8
V
SS
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
DD
G
B1
B2
B3
B4
B5
B6
B7
B8
20-Lead Flatpack
Top View
DIR
A1
A2
A3
A4
A5
A6
A7
A8
V
SS
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
DD
G
B1
B2
B3
B4
B5
B6
B7
B8
LOGIC SYMBOL
G
DIR
(19)
(1)
G3
3 EN1 (BA)
3 EN2 (AB)
(18)
1
2
(17)
(16)
(15)
(14)
B1
B2
B3
B4
A1
A2
A3
A4
A5
A6
A7
A8
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
B5
(13)
B6
(12)
B7
(11)
B8
Note:
1. Logic symbol in accordance with ANSI/IEEE Std 91-1984 and IEC
Publication 617-12.
165
RadHard MSI Logic
