PRELIMINARY
UPSC203/UPSC403/UPSC603
WATERTOWN DIVISION
Silicon Carbide Schottky Rectifiers
P
RODUCT
P
REVIEW
DESCRIPTION
KEY FEATURES
W W W.
Microsemi
.COM
In Microsemi鈥檚 new Powermite
廬
3
package, these high efficiency ultrafast
rectifiers offer the power handling
capabilities previously found only in
much larger packages. They are ideal
for SMD applications that operate at
high frequencies.
In addition to its size advantages,
Powermite
廬
3 package features include a
full metallic bottom that eliminates the
possibility of solder flux entrapment during
assembly, and a unique locking tab acts as
an integral heat sink. Its innovative design
makes this device ideal for use with
automatic insertion equipment.
IMPORTANT:
For the most current data, consult
MICROSEMI鈥檚
website:
http://www.microsemi.com
ABSOLUTE MAXIMUM RATINGS AT 25潞 C
(UNLESS OTHERWISE SPECIFIED)
Rating
Maximum Reverse Voltage, UPSC203
Maximum Reverse Voltage, UPSC403
Maximum Reverse Voltage, UPSC603
Maximum Average Output Current,
T
TAB
=75擄C
Non-Repetitive Sinusoidal Surge Current
(8.3 mS)
Storage Temperature
Operating Temperature
Symbol
V
V
V
T
I
T stg
T op
Value
200
400
600
4.0
15
-55 to +150
-55 to +150
Unit
Vdc
Vdc
Vdc
Adc
A
潞C
潞C
High power surface mount
package.
Silicon carbide Schottky rectifiers
no reverse voltage recovery.
Internal heat sink locking tabs
Low forward voltage.
Full metallic bottom eliminates
flux entrapment
Compatible with automatic
insertion equipment
Low profile-maximum height of
1mm supplied in 16 mm tape
reel- 6000 units/ 13鈥?reel.
APPLICATIONS/BENEFITS
APPLICATIONS/BENEFITS
Switching and Regulating Power
Supplies.
Charge Pump Circuits.
Reduces reverse recovery loss
due to low IRM.
Small foot print
190 X 300 mils
1:1 Actual size
THERMAL CHARACTERISTICS
(UNLESS OTHERWISE SPECIFIED)
Thermal Resistance
Junction-to Tab
Junction-to Bottom
(1) When Mounted on PC board with 2 ounce copper pattern.
Rjtab
Rja (1)
7.5
2.5
潞C/Watt
潞C/Watt
UPSC203/403/603
UPSC203/403/603
Copyright
錚?/div>
2001
Rev. 0.02, 2001-09-27
Microsemi
580 Pleasant Street, Watertown, MA. 02472-2408, 617-926-0404, Fax: 617-924-1235
Page 1
