PRELIMINARY
UPR802, UPR804, UPR806
WATERTOWN DIVISION
Surface Mount UES Rectifiers
P
RODUCT
P
REVIEW
DESCRIPTION
KEY FEATURES
W W W.
Microsemi
.COM
This state of the art high frequency
rectifier is ideally suited for
applications requiring high
blocking voltage. It has the ability
to switch significant current with
minimal switching transients and
losses. Leakage current at high
temperature has been minimized;
achieving exceptionally low reverse loses.
An ultra stable process ensures high
reliability and long life.
This device is designed for a wide variety of
high-frequency applications.
Ultra Fast Recovery-35ns
Controlled Avalanche
High Temperature Operation
with Low Loss
Minimal Recovery Transients
Low Turn-on Voltage
Powermite 3 Package
IMPORTANT:
For the most current data, consult
MICROSEMI鈥檚website:http://www.microsemi.com
APPLICATIONS/BENEFITS
APPLICATIONS/BENEFITS
Battery Charger and Switching
Circuits Where the intrinsic
source-drain diode is an
undesirable feature
Small foot print
ABSOLUTE MAXIMUM RATINGS AT 25潞 C
(UNLESS OTHERWISE SPECIFIED)
Rating
Peak Reverse Voltage UPR802
Peak Reverse Voltage UPR804
Peak Reverse Voltage UPR806
Average DC Output Current Tc = 130 潞C
Peak Forward Surge Current 8.3 mS
Storage Temperature
Operating Temperature
Symbol
V
R1
V
R1
V
R1
Io
V
F
T stg
T op
Value
200
400
600
8
100
-55 to 150
-55 to 150
Unit
V
V
V
A
A
潞C
潞C
THERMAL CHARACTERISTICS
(UNLESS OTHERWISE SPECIFIED)
Thermal Resistance
Junction-to Case
Rjtab
2.0
潞C/Watt
(1) Mounted on 2鈥?square by 0.06鈥?thick FR4 board with a 1鈥?x 1鈥?square 2 ounce copper pattern.
(2) Mounted on 0.06 thick FR4 board, using recommended footprint.
UPR802, 804, 806
UPR802, 804, 806
Copyright
錚?/div>
2001
Rev. 0.02, 2001-04-30
Microsemi
580 Pleasant Street, Watertown, MA. 02472-2408, 617-926-0404, Fax: 617-924-1235
Page 1
