UPD784054GCA1 Datasheet

  • UPD784054GCA1

  • 16-BIT SINGLE-CHIP MICROCONTROLLER

  • 86頁

  • NEC   NEC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD784054(A)
16-BIT SINGLE-CHIP MICROCONTROLLER
DESCRIPTION
The
碌
PD784054(A) is a product of the 78K/IV series, and based on the
碌
PD784044(A) with the real-time output
function and two units of timers/counters deleted and a standby function invalid mode provided. A stricter quality
assurance program applies to the
碌
PD784054(A) compared to the
碌
PD784054 (standard model).
The
碌
PD784054(A) is provided with many peripheral hardware functions such as ROM, RAM, I/O port, 10-bit
resolution A/D converter, timer, serial interface, and interrupt functions, in addition to a high-speed, high-performance
CPU.
Moreover, a flash memory model,
碌
PD78F4046
Note
, that can operate on the same supply voltage as the mask ROM
model, and many development tools are under development.
Note
Use for functional evaluation only.
The functions are described in detail in the following User鈥檚 Manuals. Be sure to read these manuals when
designing your system.
碌
PD784054 User鈥檚 Manual - Hardware
: U11719E
78K/IV Series User鈥檚 Manual - Instruction : U10905E
FEATURES
鈥?Higher reliability compared to the
碌
PD784054
鈥?Minimum instruction execution time
鈥?I/O port
鈥?Timer
鈥?A/D converter
鈥?Watchdog timer
鈥?Supply voltage
: 160 ns (with 12.5-MHz internal clock) 路路路
碌
PD784054(A)
200 ns (with 10-MHz internal clock) 路路路
碌
PD784054(A1), (A2)
: 64 lines
: 16-bit timer
脳
3 units
: 10-bit resolution
脳
16 channels
: 1 channel
: V
DD
= 4.5 to 5.5 V
鈥?Serial interface UART/IOE (3-wire serial I/O) : 2 channels
鈥?Standby function HALT/STOP/IDLE/standby function invalid mode
APPLICATION FIELDS
Automotive appliances, etc.
In this document, in addition to the
碌
PD784054(A), the
碌
PD784054(A1) and 784054(A2) are also explained.
However, unless otherwise specified, the
碌
PD784054(A) is treated as the representative model throughout
this document.
The information in this document is subject to change without notice.
Document No. U13122EJ1V0DS00 (1st edition)
Date Published January 1998 N CP(K)
Printed in Japan
漏
1998
