UPD784038GC-XXX-8BT Datasheet

  • UPD784038GC-XXX-8BT

  • MICROCONTROLLER|16-BIT|UPD78K4 CPU|CMOS|QFP|80PIN|PLASTIC

  • 98頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
MOS INTEGRATED CIRCUIT
碌
PD784035, 784036, 784037, 784038
16/8-BIT SINGLE-CHIP MICROCONTROLLER
The
碌
PD784038 is a product of the
碌
PD784038 sub-series in the 78K/IV series. It contains various peripheral
hardware such as ROM, RAM, I/O ports, 8-bit resolution A/D and D/A converters, timers, serial interface, and interrupt
functions, as well as a high-speed, high-performance CPU.
In addition, the
碌
PD78P4038 (one-time PROM or EPROM product), which can be operated within the same power
supply voltage ranges as masked-ROM products, and development tools are supported.
For specific functions and other detailed information, consult the following user鈥檚 manual.
This manual is required reading for design work.
碌
PD784038, 784038Y Sub-Series User鈥檚 Manual, Hardware : U11316E
78K/IV Series User鈥檚 Manual, Instruction
: U10905E
FEATURES
鈥?Pin-compatible with the
碌
PD78234,
碌
PD784026, and
鈥?Serial interface: 3 channels
UART/IOE (3-wire serial I/O): 2 channels
CSI (3-wire serial I/O, 2-wire serial I/O): 1 channel
鈥?PWM outputs: 2
鈥?Standby function
HALT/STOP/IDLE mode
鈥?Clock frequency division function
鈥?Watchdog timer: 1 channel
鈥?Clock output function
Selectable from f
CLK
, f
CLK
/2, f
CLK
/4, f
CLK
/8, or f
CLK
/16
鈥?Supply voltage: V
DD
= 2.7 to 5.5 V
碌
PD784038Y sub-series
鈥?Expanded internal memory spaces in the
碌
PD78234
and
碌
PD784026 sub-series
鈥?Minimum instruction execution time: 125 ns
(at 32 MHz)
鈥?Number of I/O ports: 64
鈥?Timer/counters: 16-bit timer/counter
脳
3 units
16-bit timer
脳
1 unit
鈥?A/D converter: 8-bit resolution
脳
8 channels
鈥?D/A converter: 8-bit resolution
脳
2 channels
APPLICATIONS
LBP, automatic-focusing camera, PPC, printer, electronic typewriter, air conditioner, electronic musical instru-
ments, cellular telephone, etc.
This manual describes the
碌
PD784038 unless otherwise specified.
The information in this document is subject to change without notice.
Document No. U10847EJ2V0DS00 (2nd edition)
Date Published February 1998 J CP(K)
Printed in Japan
The mark
shows major revised points.
漏
1995
