DATA SHEET

MOS INTEGRATED CIRCUIT

碌

PD78011H, 78012H, 78013H, 78014H

8-BIT SINGLE-CHIP MICROCONTROLLER

DESCRIPTION

The

碌

PD78011H, 78012H, 78013H, and 78014H are the products in the

碌

PD78014H subseries within the 78K/0 series.

Compared with the older

碌

PD78018F subseries, this subseries reduces the EMI (Electro Magnetic Interface) noise

generated from the microcontroller.

Functions are described in detail in the following User's Manual, which should be read when carring out design

work.

碌

PD78014H Subseries User's Manual: Planned to publish

78K/0 Series User鈥檚 Manual 鈥?Instruction: IEU-1372

FEATURES

鈥?/div>

Low EMI noise model

鈥?/div>

Large on-chip ROM & RAM

Item

Product Name

Program

Memory

(ROM)

8K bytes

16K bytes

24K bytes

32K bytes

Data Memory

Internal High-

Speed RAM

512 bytes

Internal

Buffer RAM

32 bytes

Package

鈥?/div>

64-pin plastic shrink DIP (750 mil)

鈥?/div>

64-pin plastic QFP (14

脳

14 mm)

1024 bytes

鈥?/div>

64-pin plastic LQFP (12

脳

12 mm)

碌

PD78011H

碌

PD78012H

碌

PD78013H

碌

PD78014H

鈥?/div>

External memory expansion space : 64K bytes

Instruction execution time can be varied from high-speed (0.4

碌

s) to ultra-low-speed (122

碌

I/O ports: 53 (N-ch open-drain : 4)

8-bit resolution A/D converter : 8 channels

Serial interface : 2 channels

Timer : 5 channels

Supply voltage : V

= 1.8 to 5.5 V

APPLICATION FIELD

Cellular phone, pager, VCR, audio, camera, home appliances, etc.

The information in this document is subject to change without notice.

Document No. U11898EJ1V0DS00 (1st edition)

Date Published January 1997 N

Printed in Japan

漏

1997
